Yog tias koj tau nyob hauvteeb pom kev zookev lag luam ib pliag, koj yuav pom tias "Qhov chav tsev loj npaum li cas no haum rau?" yog tsis tu ncua ntawm peb cov lus nug saum toj kawg nkaus nug los ntawm cov neeg siv khoom. Ntau qhov kawg- cov neeg siv xaiv teeb pom kev zoo raws li qhov xav tau; ib qho khoom siv me me dhau los ua rau lub teeb pom kev tsis zoo thiab tsis muaj qhov tob, thaum ib qho loj heev tuaj yeem xav tias tsim txom thiab khib nyiab. Raws li tus neeg muag khoom, muab cov lus qhia meej me me ua ntej-txawm yog nyob rau nplooj ntawv cov khoom lossis thaum muaj kev sib cuam tshuam cov neeg siv khoom- tsis yog tsuas yog txo qhov ntim ntawm tom qab- kev nug txog kev muag khoom tab sis kuj qhia koj txoj kev tshaj lij thiab kev ntseeg siab. Tsab ntawv xov xwm no qhia txog cov laj thawj hauv qab qhov sib xws -mount lub teeb qhov loj me rau chav qhov ntev, ua kom yooj yim rau koj los muab cov ntaub ntawv no rau hauv cov lus piav qhia khoom lossis cov neeg siv khoom Q&A ntu.
Vim Li Cas Teeb Qhov Teeb Meem Tseem Ceeb
Yog tias qhov chaw-mount lub teeb me dhau, qhov teeb pom kev zoo yuav tsis ncav cuag cov ces kaum ntawm chav tsev- ua rau nws tsaus dhau los nyeem tau yooj yim thaum zaum ntawm kaum ntawm lub rooj zaum. Hloov pauv, yog tias qhov khoom siv loj dhau lawm, nws tsim qhov pom kev sab saum toj - hnyav saib; Qhov no yog qhov teeb meem tshwj xeeb hauv cov tsev uas tsis tshua muaj qab nthab, qhov twg lub teeb pom kev loj tuaj yeem tsim kev nkag siab ntawm kev tsim txom thaum ib tus nkag mus rau hauv chav. Thaum kawg, xaiv qhov loj me yog qhov teeb meem ntawm kev ntsuas qhov pom kev nrog qhov sib npaug; nws tsis yooj yim li piv txwv tias "loj txhais tau tias ci dua."
Sib piv Chav Cheeb Tsam rau Fixture Diameter
Ib txoj cai ntawm tus ntiv tes xoo hauv kev lag luam yog muab cov chav tsev sib npaug (hauv square feet) los ntawm 1.5; qhov tshwm sim daim duab roughly qhia qhov tsim nyog fixture txoj kab uas hla nyob rau hauv nti. Txhawm rau ua kom yooj yim rau cov neeg siv khoom hauv tsev kom nkag siab hauv cov ntsiab lus metric (square meters), koj tuaj yeem siv cov lus qhia yooj yim no:
Rau chav ntawm 6-10 m²:Pom zoo fixture txoj kab uas hla ntawm 30-40 cm
10-15 m²:Pom zoo 40-50 cm
15-20 m²:Pom zoo 50-60 cm
Rau chav loj dua 20 m²:Feem ntau nws yog qhov zoo dua los siv kev sib xyaw ntawm ntau lub teeb lossis kev sib xyaw ntawm cov teeb pendant thiab nto -mount teeb, es tsis yog tsuas yog nce qhov loj ntawm ib qho khoom siv xwb.
Cov qauv no tsis yog ib qho kev tshawb fawb tseeb tab sis yog qhov pib; cov kev xaiv tshwj xeeb yuav tsum zoo-tuned raws li cov yam ntxwv xws li chav tsev, qab nthab qhov siab, thiab phab ntsa xim (cov phab ntsa tsaus nti nqus lub teeb, yog li tib lub wattage yuav tshwm sim dimmer).
Qhov cuam tshuam ntawm Ceiling Qhov siab ntawm kev xaiv loj
Qab nthab qhov siab yog lwm qhov sib txawv uas yooj yim saib. Rau cov qauv qab nthab qhov siab (2.4–2.7 meters), tus qauv -thickness flush-mount teeb ua haujlwm zoo; Txawm li cas los xij, yog tias lub qab nthab qhov siab qis dua 2.4 meters, ua qhov tseem ceeb ntawm ultra- qauv slim-hom phiaj ua kom lub thickness ntawm lub fixture nyob rau hauv 5 centimeters-kom tsis txhob pom lub qab nthab qis dua. Hloov pauv, yog tias lub qab nthab qhov siab tshaj 3 meters, lub teeb pom kev zoo yuav tsis pom qhov pom; Nyob rau hauv cov ntaub ntawv no, xaiv rau ib tug loj txoj kab uas hla los yog ib tug multi- lub taub hau fixture yuav tsim ib tug ntau sib npaug.
Xam cov Wattage thiab Lumen Requirements
Thaum qhov loj me tau txiav txim siab, lub zog yuav tsum sib phim; txwv tsis pub, kev sib koom ua ke nrog lub teeb pom kev loj nrog cov zis hluav taws xob tsawg yuav ua rau lub teeb pom kev tsis txaus. Ib txoj cai ntawm tus ntiv tes xoo yog tso cai rau kwv yees li 100-150 lumens ib square meter (siv qis kawg ntawm qhov chaw rau qhov chaw uas xav tau teeb pom kev zoo, xws li chav nyob thiab chav pw, thiab qhov kawg siab dua rau thaj chaw xav tau teeb pom kev zoo rau kev ua haujlwm ntxaws, xws li chav ua noj thiab kev kawm). Piv txwv li, 12-square-meter chav pw yuav tsum kwv yees li 1,200–1,800 lumens, uas sib haum rau LED teeb ntawm li 15-20 watts (nyob ntawm seb qhov kev ua tau zoo ntawm LED chips). V. Cov lus qhia tshwj xeeb los ntawm Chav Tsev
Chav pw:Ua ntej teeb pom kev zoo; ib lub fixture nrog ib txoj kab uas hla 40-50 cm thiab adjustable xim kub yog cov tswv yim. Tsis txhob coj lub teeb ncaj nraim mus rau saum txaj.
Chav nyob:Feem ntau yog ib cheeb tsam loj; ib qho kev sib tw loj dua 50 cm lossis ua ke ntawm lub teeb tseem ceeb ntxiv rau cov teeb pom kev zoo / LED strips yog pom zoo.
Chav ua noj: Yuav tsum muaj xim rendering thiab illuminance; xaiv ib txoj kab uas hla 30-40 cm thiab siab dua wattage.
Chav dej:Ua ntej cov dej noo thiab huab cua tiv thaiv (tsawg kawg IP44 ntsuas); 30 cm puag ncig lossis square qauv yog ntau.
Hallway / Nkag:Cov no yog qhov nqaim, elongated qhov chaw; xaiv cov khoom me me (20-30 cm) thiab tso lawv tawm es tsis siv lub teeb loj loj kom ntseeg tau tias muaj teeb pom kev zoo dua.
Common Size Specifications
Raws li kev lag luam xav tau, cov kab hauv qab no specifications yog nrov tshaj plaws:
300mm (kwv yees . 12 ntiv tes):Tsim nyog rau chav pw me me, chav tsev, thiab chav dej.
400mm (kwv yees . 16 ntiv tes):Haum rau nruab nrab - chav pw thiab kev kawm.
500mm (kwv yees . 20 ntiv tes):Haum rau chav nyob thiab chav noj mov.
600mm thiab siab dua:Haum rau chav nyob loj lossis chaw lag luam; feem ntau muaj nyob rau hauv tsis yog - cov qauv zoo li cov squares lossis hnub qub.
Common Installation Pitfalls
Thaum kawg, ntawm no yog ob feem ntau- tsis saib xyuas cov ntsiab lus: Ua ntej, qhov kev sib tw yuav tsum nyob nruab nrab kom ntau li ntau tau; qhov tseem ceeb tawm - qhov chaw muab tso rau hauv nruab nrab ua rau lub teeb tsis sib xws. Thib ob, ua ntej kev yuav khoom, xyuas kom meej tias txoj kev teeb tsa-nto-mounted, recessed, los yog raug ncua- yog sib xws nrog koj cov qauv qab nthab. Load-cov kabmob muaj peev xwm sib txawv ntawm, piv txwv li, plasterboard suspended ceilings thiab pob zeb ceilings; xaiv txoj kev tsis ncaj ncees lawm yuav ua rau raug nqi rov ua dua.
Hauv cov ntsiab lus: Tsis muaj "ib-qhov loj me- haum-tag nrho" cov lus teb rau lub qab nthab teeb qhov ntau thiab tsawg, tab sis xav txog chav tsev, qab nthab qhov siab, thiab chav ua haujlwm yuav pab koj txo qis cov kev xaiv rau ntau yam tsim nyog. Rau cov neeg yuav khoom thiab cov neeg xa khoom, kev nkag siab txog qhov kev xav no tsis yog tsuas yog ua kom yooj yim xaiv cov khoom lag luam tab sis kuj tseem ua kom muaj kev taw qhia zoo dua rau cov neeg siv khoom kawg, yog li txo qis rov qab, kev sib pauv, thiab kev tshuaj xyuas tsis zoo. Yog tias koj tab tom nrhiav cov teeb ci qab nthab nrog qhov loj thiab wattage rau koj qhov project lossis lub khw, thov qhia koj cov kev xav tau-xws li chav qhov ntev, qab nthab qhov siab, thiab xim kub nyiam- nrog peb. Peb tuaj yeem pom zoo kom tsim nyog specifications thiab qauv raws li qhov tseeb daim ntawv thov scenario thiab kuj muaj kev cai prototyping; thov koj xav tiv tauj peb txhua lub sijhawm.
