kev sib piv ntawm cov khoom parameter
| Input voltage (V) | AC85-265V | Hom puag | E27 |
| Lifespan (teev) | 50000 | Lub teeb Luminous Efficiency (lm / w) | 100 |
| Xim kub (CCT) | 2700-6500K | Daim ntawv pov thawj | RoHS, CE |
| Warranty (Xyoo) | 2 | Txhawb Dimmer | Tsis muaj |
| Xim Rendering Index (Ra) | 80 | Hom | Lub teeb |
| Daim ntawv thov | Vaj | Hloov hom | Lwm yam |
| Hwj chim Source | DC | Khoom siv | Aluminium |
| Teeb pom kev daws teeb meem kev pabcuam | Teeb pom kev zoo thiab Circuitry tsim, qhov project installation |
Qhov Chaw Keeb Kwm |
Guangdong, Suav teb |
| Lub teeb Luminous Flux (lm) | 1800 | Khoom hnyav (kg) | 5 |
| Ua haujlwm kub (degree) | -20 - 60 | Khoom npe | LED Teeb Lub Teeb |
| Hwj chim | 80W 100W 120W | Khoom siv | Aluminium |
| CCT |
6500K |
Hom | coj qhov muag teev e27 250w |
Core Performance
Txais siab -kev ua tau zoo 2835 SMD LED chips nrog zoo luminous efficiency txog li 140lm/W, CRI＞80, adjustable xim kub xws li ntawm 2700K sov dawb mus rau 6500K txias dawb. Featuring 360℃omnidirectional ib puag ncig teeb pom kev zoo nrog dual -sab nti kev teeb tsa ntawm sab & hauv qab, xoom qhov chaw tsaus thiab tsis muaj flickering. Nws hloov tau cov teeb pom kev zoo ib txwm muaj, hlau halide & siab - siab mercury teeb, xa ntau dua 3.5 × siab dua ci ntsa iab thaum txiav hluav taws xob siv los ntawm 75% -80% kom txiav ntev -cov nqi hluav taws xob rau cov neeg siv khoom lag luam & kev lag luam.
Nruab nrog tag nrho -ntau qhov dav qhov hluav taws xob sib cais tsis tu ncua- tsav tsheb tam sim no (AC100–305V universal input) tau sib xws nrog cov phiaj xwm loj hauv ntiaj teb. Cov khoom tseem ceeb suav nrog Ruby electrolytic capacitors thiab qib siab -qib MOSFET chips, lub zog hluav taws xob tau ntim nrog cov thermal conductive silicone kua nplaum rau kev tiv thaiv kaw, ua -hauv EMC los tiv thaiv- cuam tshuam & surge tiv thaiv circuits kom ruaj khov tso zis hauv qab ± 20% daim phiaj hluav taws xob hloov pauv, ua kom muaj txiaj ntsig zoo. Txhua lub teeb ua tau raws li CE, RoHS & ETL daim ntawv pov thawj rau kev lis kev cai du thoob plaws Europe, North America thiab Southeast Asia.
6063 extruded aluminium vaj tse nrog anodized anti-corrosion & anti- zoo li qub tag thiab ntau-groove convection cua txias channel. High thermal conductivity aluminium sai dissipates kev khiav hauj lwm kub ntawm ntuj cua convection los tswj nti hlws ris kub thiab qeeb luminous depreciation. Ntau lub hauv paus kev xaiv: E26/E27/E39/E40 rau ntsaws-thiab- ua si retrofit, tsis muaj ballast ntxiv lossis rewiring xav tau los hloov cov teeb qub, txo qis kev kho dua tshiab thiab cov nqi ntxiv.
Service Life & Lumen Depreciation
Rated lifespan:50,000 teev ua haujlwm. Ua haujlwm 10 teev txhua hnub, lub teeb ua haujlwm tsis tu ncua rau ntau tshaj 13 xyoos, ntau dua 10 × ntev dua li cov teeb pom kev zoo hlau halide (3,000–5,000hrs). Qhov zoo tshaj plaws rau kev nyuaj-mus- mus txog siab- qab nthab warehouses, supermarkets thiab chaw ua haujlwm kom txo qis kev hloov pauv & kev siv nyiaj ntau.
Kev soj ntsuam nruj me ntsis rau LM-80 tus qauv rau kev saib xyuas lumen: Tsawg dua lossis sib npaug li 5% lumen depreciation tom qab siv 3,000hrs, Tsawg dua lossis sib npaug li 12% poob tom qab 10,000hrs, thiab tshaj 70% lumen tuav ntawm qhov kawg ntawm 50,000-teev lifespan. Optimized tshav kub dissipation thiab tas li-tam sim no tsim tiv thaiv sai sai thaum ntxov brightness poob los ntawm overheating.
Cov neeg tsav tsheb puv potted khaws cov khoom siv sab hauv kom deb ntawm cov plua plav & dej noo, txwv lub capacitor kev khiav hauj lwm kub qis dua 85℃thiab ncua kev pab cuam tsav tsheb 3 × ntev dua li qub tsis yog - potted counterparts, ua tiav ultra- tsawg tsis ua hauj lwm nyob rau hauv ntev - lub sij hawm ua lag luam mus tas li.
Ingress Protection & Environmental Adaptability
IP54 Ingress tiv thaiv ntsuas
IP5X plua plav pov thawj: kaw aluminium & yas siv thaiv cov plua plav zoo, lint thiab kab los ntawm invading puab circuits, haum rau plua plav rhiav, grain cia barns thiab ua liaj ua teb tsev cog khoom.
IPX4 txaws- pov thawj: Tiv thaiv cov dej txaws los ntawm txhua qhov kev qhia, muaj rau eaave- teeb pom kev sab nraum zoov, qhib- cov khw muag khoom huab cua thiab cov teeb pom kev lag luam yam tsis muaj luv luv - Circuit Court txaus ntshai nyob rau hnub los nag.
Kev khiav hauj lwm dav ntawm qhov kub ntawm -35℃rau +55 degree, ntseeg tau tig rau thiab khiav ruaj khov nyob rau hauv lub caij ntuj no txias Nordic thiab sweltering tropical summers rau thoob ntiaj teb xa mus.
