- Nta
1. Ib lub teeb ci LED uas tawm 180 lumens ib watt thiab siv 500 watts.
2. Meanwell LED tsav tsheb nrog tag nrho kev sib haum xeeb distortion (THD) tsawg dua 15%, kev ua haujlwm voltage ntawm AC185 txog 305 volts, thiab kev khiav hauj lwm voltage ntawm 100 mus rau 480 volts.
3. Lub luminosity tau txo qis dua 10% tom qab tsib xyoos. L70 tau sau ntau tshaj 50, 000 teev.
4. Ib qho kev sib koom ua ke uas muaj txiaj ntsig zoo dissipates tshav kub thiab tswj qhov kub hauv qab 70 degree yuav muaj lub neej ntev dua.
5. Ib txoj hauv kev rau kev ntse dimming teeb.Versions uas kho tau muaj nyob rau hauv 0V–10V, DMX, thiab DALI.
- Specification
|
Hwj chim |
100W |
200W |
300W |
400W |
500W |
600W |
800W |
1000W |
|
LED (pcs) |
48 |
96 |
144 |
192 |
240 |
288 |
384 |
480 |
| Dimension (mm) |
210*350*65 |
315*350*73 |
450*350*73 |
580*350*73 |
710*350*73 |
450*620*730 |
580*620*730 |
710*620*730 |
|
Qhov hnyav (kg) |
3.5 |
4.5 |
5.6 |
6.5 |
7.5 |
14.2 |
16 |
18 |
|
Input voltage |
AC 85-265V |
|||||||
|
CRI (Ra>) |
>80 |
|||||||
|
Daim ntawv pov thawj |
CE, ROSH daim ntawv pov thawj |
|||||||
|
Beam Angle |
8 degree / 20 degree / 40 degree / 60 degree / 90 degree / 140 degree |
|||||||
|
Lub teeb Source |
3030/3535/5050 |
|||||||
|
IP Qib |
Waterproof IP66 |
|||||||
|
Khoom siv |
Aluminium |
|||||||
|
CCT |
3000/4500/5700/6500K |
|||||||
|
Warranty |
5 xyoo |
|||||||
- Paub meej ntxiv
- Daim ntawv thov
• Chaw nres tsheb ntau, teeb pom kev hauv tsev, teeb pom kev ua liaj ua teb
• Cricket Stadium, nees barn, Baseball teb
• Tennis Court, ntaus golf, ncaws pob ncaws pob
