Qhov Flexarch no nthuav tawm peb cov kev muaj tswv yim txuas ntxiv hauv kev tsim cov khoom tshiab. Txhawm rau muab qhov kev sib haum xeeb zoo tshaj plaws, cov teeb pom kev zoo tshaj plaws thaum ua nws qhov ncaj ncees thiab pheej yig tshaj plaws, peb xav kom muaj kev pabcuam rau cov teeb pom kev zoo tsim teeb pom kev zoo, cov neeg cog lus, installers, thiab cov neeg.
Product Description
1. Ua haujlwm ntawm qhov siab tshaj plaws ntawm 24VDC thiab 18W / meter (dawb).
2.Txog 120LM / W rau 4000K zaub.
3.Ntau tshaj 5 meters nyob rau hauv ib tug nruam khiav.
4.Project ntxuav cov phab ntsa qhov siab tshaj plaws 4 meter teeb pom kev zoo.
5. Ntawm qhov thim rov qab, 3M nplaum daim kab xev.
6.Aluminium profile thiab brackets nrog adjustable kaum sab xis yog ib feem ntawm kev xaiv aluminium profile pob.
7.Rated IP67.
Specification
| Hwj chim | LED Q'ty | Xim / CCT | CRI | Beam Angle | Tswv yim | Luminous Flux | Min. Txiav Length (mm) | Qhov Loj (W * H) | Max Continous Length rau ib qho kev khiav | IP |
| 18W/M | 48 | 2700K/3000K/4000K/6500K | Ra>90 | 30 degree, 45 degree, 60 degree, 20 * 45 degree | 24 VDC | 2167 ± 8 feem pua | 125 hli | 18.5*9.5 | 5 meters | IP67 |
| 6.2W/M | 42 | RGB | / | 15 degree, 30 degree, 45 degree, 15 * 60 degree | 24 VDC | 264 | 166.6mm 3 | 18.5*9.5 | 5 meters | IP67 |
| 8W/M | 42 | RGBW 4-hauv-1 | / | 15 degree, 30 degree, 45 degree, 15 * 60 degree | 24 VDC | 540 | 166.6mm 3 | 18.5*9.5 | 5 meters | IP67 |
Nco tseg:
1. CCT(K) (± 5%): 2700K, 3000K, 4000K, 6000K.
2. Customized ntev yog muaj.
3. Cov lus qhia tshwj xeeb thiab muaj nyob yuav raug hloov yam tsis tau ceeb toom.
Ntau cov duab:
Cov cheeb tsam ntawm kev thov:
